| Configuration Parameters Table |
| Model/ Parameter |
2023 Model Sportster S | 2024 Model Sportster S Gloss B lack |
2024 Model Sportster S Pool Ta ble Grey |
| ABS | Standard front and rear | Standard front and rear | Standard front and rear |
| ABS anti-lock braking | Standard front and rear | Standard front and rear | Standard front and rear |
| USB charging port | Standard USB | Standard USB | Standard USB |
| Launch time | 2023-01-19 | 2024-01-25 | 2024-01-25 |
| Main fuel tank capacity (L) | 11.8 | 11.8 | 11.8 |
| Instrument panel | 4-inch TFT Color Display | 4-inch TFT Color Display | 4-inch TFT Color Display |
| Transmission mode | Belt drive | Belt drive | Belt drive |
| Fuel supply method | Electronic fuel injection | Electronic fuel injection | Electronic fuel injection |
| Cooling method | Water-cooled | Water-cooled | Water-cooled |
| Forward tilt angle (°) | 30 | 30 | 30 |
| Front brake system | Single Disc with Four-piston C aliper |
Single Disc with Four-piston C aliper |
Single Disc with Four-piston C aliper |
| Front suspension system | 43mm Inverted Fork Design with Compression, Rebound and Spri ng Preload Adjustment |
43mm Inverted Fork Design with Compression, Rebound and Spri ng Preload Adjustment |
43mm Inverted Fork Design with Compression, Rebound and Spri ng Preload Adjustment |
| Headlight | LED | LED | LED |
| Front wheel specification | 160/70-R17 | 160/70-R17 | 160/70-R17 |
| Compression ratio | 12:1 | 12:1 | 12:1 |
| Reference price | 19542 USD | 19725 USD | 19542 USD |
| Engine | V-twin Cylinder Four-stroke Wa ter-cooled·1250cc |
V-twin Cylinder Four-stroke Wa ter-cooled·1250cc |
V-twin Cylinder Four-stroke Wa ter-cooled·1250cc |
| Engine stroke | Four-stroke | Four-stroke | Four-stroke |
| Engine model | Revolution® Max 1250T | Revolution® Max 1250T | Revolution® Max 1250T |
| Number of engine cylinders | Twin cylinders | Twin cylinders | Twin cylinders |
| Engine structure | V-type | V-type | V-type |
| Transmission | International 6-speed | International 6-speed | International 6-speed |
| Transmission type | International 6-speed | International 6-speed | International 6-speed |
| Available colors | Starry Sea Blue, Twilight Grey , Gloss Black, White Sand Pear l |
Gloss Black | Pool Table Grey |
| Rear brake system | Single Disc with Floating Sing le-piston Caliper |
Single Disc with Floating Sing le-piston Caliper |
Single Disc with Floating Sing le-piston Caliper |
| Rear suspension system | Link-mounted Underseat Single Shock System with Compression, Rebound and Hydraulic Spring Preload Adjustment |
Link-mounted Underseat Single Shock System with Compression, Rebound and Hydraulic Spring Preload Adjustment |
Link-mounted Underseat Single Shock System with Compression, Rebound and Hydraulic Spring Preload Adjustment |
| Rear light | LED | LED | LED |
| Rear wheel specification | 180/70-R16 | 180/70-R16 | 180/70-R16 |
| Brand | Harley-Davidson | Harley-Davidson | Harley-Davidson |
| Official average fuel consumpt ion (L/100km) |
5.1 | 4.8 | 4.8 |
| Navigation projection function | Standard equipment | Standard equipment | Standard equipment |
| Dry weight (kg) | 221 | 221 | 221 |
| Seat height (mm) | 765 | 765 | 765 |
| Cornering ABS system (ABS PRO/ ABS EVO, etc.) |
Standard equipment | Standard equipment | Standard equipment |
| Mobile phone connection functi on (Bluetooth/WIFI, etc.) |
Standard equipment | Standard equipment | Standard equipment |
| Trail (mm) | 148 | 148 | 148 |
| Gear display | Standard equipment | Standard equipment | Standard equipment |
| Displacement (cc) | 1250 | 1250 | 1250 |
| Curb weight (kg) | 228 | 228 | 228 |
| Maximum lean angle - right | - | 34 | 34 |
| Maximum lean angle - left | - | 34 | 34 |
| Maximum power (kW) | 89 | 90 | 90 |
| Maximum power/speed (kW/rpm) | 89/7500 | 90/7500 | 90/7500 |
| Maximum power speed (rpm) | 7500 | 7500 | 7500 |
| Maximum torque (N·m) | 117 | 126 | 126 |
| Maximum torque/speed (N·m/rpm) | 117/7000 | 126/6000 | 126/6000 |
| Maximum torque speed (rpm) | 7000 | 6000 | 6000 |
| Maximum horsepower (Ps) | 121.0 | 122.4 | 122.4 |
| Maximum horsepower (ps) | 121.0 | 122.4 | 122.4 |
| Minimum ground clearance (mm) | 90 | 90 | 90 |
| Fuel tank capacity (L) | 11.8 | 11.8 | 11.8 |
| Fuel type | Gasoline | Gasoline | Gasoline |
| Traction control system | Standard equipment | Standard equipment | Standard equipment |
| Clutch | Wet multi-plate clutch | Wet multi-plate clutch | Wet multi-plate clutch |
| Exact displacement (cc) | 1252 | 1252 | 1252 |
| Bore x stroke (mm) | 105x72.3 | 105x72.3 | 105x72.3 |
| Tire pressure monitoring | Standard equipment | Standard equipment | Standard equipment |
| Model | Cruise | Cruise | Cruise |
| Handlebar | - | Variable diameter | Variable diameter |
| Turn signal | LED | LED | LED |
| Tire brand | Dunlop/Harley-Davidson Series, Radial Tire |
Dunlop/Harley-Davidson Series, Radial Tire |
Dunlop/Harley-Davidson Series, Radial Tire |
| Tire type | Vacuum tire | Vacuum tire | Vacuum tire |
| Rim | Aluminum alloy cast type | Aluminum alloy cast type | Aluminum alloy cast type |
| Wheelbase (mm) | 1520 | 1520 | 1520 |
| Intake form | Naturally aspirated | Naturally aspirated | Naturally aspirated |
